JXF Series wall mounted distribution box below 400A

Product Overview

JXF series wall mounted power distribution box below 400 is the new product introduced from ABB , it has the features of compact and reasonable structure , not only instead the characteristics of FXF , but also reflects the development and direction of the modern electrical industry . JXF series wall mounted power distribution box is the distribution device designed according the the component number , specification , quantities . The products are widely used in industrial and civil buildings , Rated voltage below 380V , Frequency is 50HZ , with the function of lighting, power distribution and automatic control .

JXF series wall mounted power distribution box below 400 with the closed structure , mounted or flush installed at the wall , The box is bend and welded by cold rolled steel plate, The surface done electrostatic spray plastic treatment , beautiful and high protection performance .The door and box body are welded with grounding screws , connect with multiple soft cables , good grounding protection , The shell ingress protection is IP30 , conform with GB7251-1 and EC61439-1 standards .
