XGW-12 Ring cage(Switching station)

Function Characteristic

DFW-12 ring cage use the prefabricated live touching cable joint , full sealed , fully insulated, maintenance free . can keep the personal safe , tight structure , The appearance is small and beautiful , stainless steel double layer box body , the life span more than 20 years .

It can do the maintenance but do not affect the main network operation .

It can equip one or more sets of SF6 switch disconnector , flexible wiring mode , the branch line out can be 8 circuit .

It can equip with the lightning arrester ,  Short-circuit fault indicator , current limit fuse , satisfy kinds of the requirements .

Regular Working Conditions

  Ambient temperature : -45 ℃  ~  +45 ℃

The sea level height not above 2500m

Relative humidity :  Daily average not exceed 95% , Monthly average not exceed 90%

The installation environment shall be without obvious filth, no explosive or corrosive gas and dust  The installation site shall be free of violent shock.

DFW technical parameters
